Asus ROG Strix X670E-A Gaming WIFI DDR5 AM5 AMD ATX Gaming Motherboard – اللوحة الأم

Asus ROG Strix X670E-A Gaming WIFI DDR5 AM5 AMD ATX Gaming Motherboard – اللوحة الأم

$539.99

SKU: 10311127572467 Categories: , , , , , ,
CPU AMD
Socket AM5
Back Panel I/O 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
  8 x USB 3.2 Gen 2 ports (7 x Type-A, 1 x USB Type-C®)
  1 x USB 3.2 Gen 1 port (1 x Type-A)
  2 x USB 2.0 ports (2 x Type-A)
  1 x DisplayPort
  1 x HDMI® port
  1 x Wi-Fi Module
  1 x Intel® I225-V 2.5Gb Ethernet port
  5 x Audio jacks
  1 x Optical S/PDIF out port
  1 x BIOS FlashBack™  button
  1 x Clear CMOS button
Memory Slots 4
Storage Expansion 4 x M.2 slots and 4 x SATA 6Gb/s ports
Internal I/O Fan and Cooling related
  1 x 4-pin CPU Fan header
  1 x 4-pin CPU OPT Fan header
  1 x 4-pin AIO Pump header
  5 x 4-pin Chassis Fan headers
  Power related
  1 x 24-pin Main Power connector
  2 x 8-pin +12V Power connector
  Storage related
  4 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  USB
  1 x USB 3.2 Gen 2×2 connector (supports USB Type-C® )
  1 x USB 3.2 Gen 1 header supports additional
  2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports
  Miscellaneous
  3 x Addressable Gen 2 headers
  1 x Aura RGB header
  1 x CPU Over Voltage jumper
  1 x Front Panel Audio header (AAFP)
  1 x 20-3 pin System Panel header with Chassis intrude function
  1 x Thermal Sensor header
  1 x Thunderbolt™  header
Front Panel I/O
  Rear USB (Total 12 ports)
  1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
  8 x USB 3.2 Gen 2 ports (7 x Type-A + 1 x USB Type-C®)
  1 x USB 3.2 Gen 1 port (1 x Type-A)
  2 x USB 2.0 ports (2 x Type-A)
  Front USB (Total 7 ports)
  1 x USB 3.2 Gen 2×2 connector (supports USB Type-C® )
  1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Wireless Wi-Fi 6E
  2×2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
  Supports 2.4/5/6GHz frequency band*
  Bluetooth v5.2
Software Windows® 11, Windows® 10 64-bit
Dimensions ATX
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
